Dongguan City Xingle Electronic Insulation Material Co., Ltd.

Itw Formex PP Gk5BK Gk10BK Gk17BK Gk30BK

¥13,000.00 CNY

~~¥13,000.00 CNY~~ ¥13,000.00 CNY

促销售罄

价格 13000YUAN/ROLL

数量

(click: international alibaba)

PHONE: +86 13018633443

E-MAIL: CHENCENL@163.COM

roduct Description

ELECTRICAL INSULATION & BARRIER MATERIALS

FLAME RETARDANT UL 94 V-0 ELECTRICAL INSULATION AND MATERIALS INCLUDING POLYPROPYLENE INSULATION SHEETS

ITW Formex polypropylene and polycarbonate flame retardant electrical insulating materials provide superior electric surge shielding in industrial and consumer electronic equipment. It is also useful as a thermal and electrical barrier material which is reflected in its UL 94V-0 Flame Class Rating. FormeX heat insulating materials are available as sheets and rolls or and can be fabricated into a wide range of shapes to meet the flammability and dielectric needs of a variety of applications.

FORMEX N3 AND FORMEX CND

Halogen-Free
Multi-layer polycarbonate
UL 94V-0 Flame Class Rating
Excellent dielectric strength
UL Recognized File E121855

Formex N3 Data Sheet Formex CND Data Sheet

FORMEX GL

UL 94V-0 Flame Class Rating
H20 Absorption 0.06%
Temperature Rating 125C
Dielectric Strength 1,880 Volts/mil @ 0.010"
UL Recognized File E121855

Formex GL Data Sheet

FORMEX GS

Flammability Rating UL 94 VTM-0
H20 Absorption 0.06%
Temperature Rating 115°C/239°F
Dielectric Strength 1,683 Volts/mil @0.010"
Static Dissipative ESD protection
UL Recognized File E121855

Formex GS Data Sheet

FORMEX GK

Flammability Rating UL 94 VTM-0
H20 Absorption 0.06%
Temperature Rating 115°C/239°F
Dielectric Strength 2,200 Volts/mil @0.005"
UL Recognized File E121855

Formex GK Data Sheet

PRODUCT ADVANTAGES & BENEFITS

	UL 94 V-0 Flame Class Rating	Meets global safety standards
	Non-Hygroscopic	Ultra low moisture absorption
	Chemical Resistance	Maintains mechanical/electrical properties
	Superior Dielectric Breakdown	Shields electricity from electric surge
	Excellent Score and Fold	Parts will not crack or split Ships flat to save freight costs
	Cost-Effective	Lower overall part cost with thinner materials
	Static Dissipative (Formex™ GS)	Dissipates static electrical charge to a ground
