Japan Toyo NF77 Vulcanized Fiberboard
Japan Toyo NF77 Vulcanized Fiberboard
无法加载取货服务可用情况
(click: international alibaba)
PHONE: +86 13018633443
E-MAIL: CHENCENL@163.COM
Japan's North Vietnam Toyo vulcanized fiberboard is made of wood pulp and cotton pulp with natural insulation, arc resistance, oil resistance and easy processing. Can be used for weak or heavy electrical equipment.
uses natural materials and is made of base paper from cotton pulp and refined wood pulp. After the base paper is immersed in a zinc chloride solution and the base paper is laminated to a desired thickness, the residual zinc chloride solution is sufficiently removed by a water washing method, and the vulcanized fiberboard is formed by a drying process.
Product Overview
Japan Toyo Vulcanized Fiberboard
Basic performance
Toyo vulcanized fiberboard is made of natural materials. With the following diverse features:
‧Good mechanical properties
‧ impact resistance, wear resistance, compression resistance, good toughness
‧Lightweight, oil resistant, chemical resistant
‧Not hot, no condensation, absorption/release of moisture
‧Biodegradable and antistatic properties
Product specifications
|
type |
specification |
colour |
thickness(mm) |
feature |
|
Ordinary toyo fiber |
HB-77 |
N、R、B、SW |
0.25~2.6 |
Excellent processing properties Electrical insulation properties Antistatic properties High toughness |
|
FP |
DB |
0.1~0.8 |
It is made of cotton pulp as the main raw material, has excellent heat resistance and processing properties, and is mainly used as an electrical insulating material. |
|
|
SF-03 |
- |
- |
It is used in a variety of products that require exceptional softness and excellent bending properties. |
|
|
Waterproof, heat resistant toyo fiber |
K-57 |
N、R、B、SW |
0.5~2.6 |
Excellent heat resistance Excellent water resistance Dimensional stability |
|
RK-76 |
N、R、B、SW |
0.25~2.0 |
Excellent water resistance, moisture resistance, excellent anti-aging properties, excellent arc resistance, impact resistance, dimensional stability |
|
|
RGFK-57 |
N |
1.0~2.0 |
The cotton pulp and the glass fiber are combined and added to a special resin. It is dimensionally stable and has excellent heat resistance. |
|
|
Fireproof toyo fiber |
NF-77 |
N、R、B、SW |
0.25~1.6 |
Fireproof products, UL certified products. Excellent processing properties Excellent electrical insulation properties |
|
NF-2000 |
N |
0.25~1.6 |
Halogen-free fireproof product |
|
|
RNF-77 |
N、R、B、SW |
0.25~1.6 |
The NF-77 is treated with advanced fire-resistant urethane to improve the waterproof performance, electrical insulation performance and improved moisture absorption. Low product |
|
|
NF-95FP |
N、R、B、SW |
0.18~0.5 |
Fireproof FP products |
|
|
RNF-97FP |
N、R、B、SW |
0.18~0.5 |
Fireproof FP product coated with fireproof urethane |
|
|
NFK-88 |
CH |
0.5~1.0 |
Fireproof, waterproof, UL recognized type toyo fiber |
|
|
RNFK-88 |
CH |
0.5~1.0 |
The NFK-88 is treated with advanced fire-resistant urethane to improve the waterproof performance, electrical insulation properties and improved insulation of the product due to moisture absorption. |
|
|
Laminated toyo fiber |
VFG |
N、R、B、SW |
3.0~50.0 |
Made of 1.0mm, 1.2mm toyo fiber laminate. Can be machined for electrical insulation, sporting goods and other industries |
|
VF-67 |
N、R、B、SW |
3.0~50.0 |
Made of 0.5 mm resin impregnated Toyo fiber laminate. Can be machined for electrical insulation, sporting goods and other industries |
|
|
Toyo fiber for grinding |
- |
|
0.5~1.2 |
As a substrate for polishing, the corresponding severe conditions are satisfied. Using advanced cotton pulp combined with Toyo's own special process to manufacture advanced high-level products |
Applications
Toyo vulcanized fiberboard is made from selected cotton pulp and wood pulp. It is a green and environmentally friendly product. It can be returned to nature through microbial decomposition. As a non-hazardous, environmentally friendly vulcanized fiberboard, it is widely used for its excellent properties:
‧Weak electricity, heavy equipment parts
‧Mechanical parts
‧Material for grinding products
‧Construction materials such as containers and bags
‧Stationery, hooking tools, cutting tools, etc.
