Dongguan City Xingle Electronic Insulation Material Co., Ltd.

Rogers Poron & Bisco Silicone Series HT-800 BF100 Silicone Foam Data Sheet 4790 4701

Rogers Poron & Bisco Silicone Series HT-800 BF100 Silicone Foam Data Sheet 4790 4701

¥2,000.00 CNY
¥350.00 CNY ¥2,000.00 CNY
促销 售罄
PRICE

(click:  international alibaba)

PHONE:    +86 13018633443

E-MAIL:     CHENCENL@163.COM



Specification
item
value
Place of Origin
China
Brand Name
BISCO
Model Number
HT-800 BF1000 4701 4790
Type
Other
Material
Silicone Foam
Application
High Temperature
Rated Voltage
200
Color
Black,GREY
BISCO HT-800 Medium Cellular Silicone is a versatile, medium firmness silicone. HT-800 silicone foam leads the market in sealing
and protecting outdoor communication, electronics and lighting enclosures. HT-800 silicone foam's superb memory and low stress
relaxation reduces maintenance costs from gasket failures caused by compression set and softening. Its compact cell structure and
unique formulation provide enhanced sealing against penetration from fine particles and wind-driven rain and fire. It also offers
shock reduction and vibration isolation in electronic components and transportation vehicles.
Features
* Compact cell structure and unique formulation
* Available in thicknesses from 0.031 to 0.500 in.
* Typical density of 22 PCF
* CFD range of 6-14 PSI
* Resistant to UV, ozone, extreme temperatures and flame

Benefits
* FDA compliant
* Offers consistent performance in all environments
* Excellent memory and low stress relaxation
* Reduces maintenance costs associated with gasket failures due to compression set and softening




Rogers Poron Series

PORON 4701-30 Polyurethane Foam Series

* Very soft and easily compressed
* Thickness range from 0.031″ to 0.500″ (0.79 mm to 12.7 mm)
* For use in flexible gasket, gap filling and spring applications

PORON 4701-40 Polyurethane Foam Series

* Soft material series
* Thickness range from 0.031″ to 0.500″ (0.79 mm to 12.7 mm)
* For industrial gasket, electronic components sealing application

PORON 4701-50 Polyurethane Foam Series

* Firm material for managing high energy impact
* Thickness range from 0.031″ to 0.500″ (0.79 mm to 12.7 mm)
* For gasket and high energy shocked absorption

PORON 4701-60 Polyurethane Foam Series

* Very firm material for energy management solutions
* Thickness range from 0.031’’to 0.250’’ (0.79 mm to 6.35 mm)
* Suitable for high energy shock absorption such as cushioning and utensil foot pad

PORON 4790-92 Polyurethane Foam Series

* Extra soft material
* Thickness range from 0.021″ to 0.500″ (0.53 mm to 12.7 mm)
* Suitable for industrial sealing and anti shocked application

PORON 4790-79 Polyurethane Foam Series

* Multiple densities available for varying designs
* Thickness range from 0.10 to 0.3 mm (0.004 to 0.012 in.)
* Mainly used to protect battery, LCD Screen, electronic components, etc

PORON 4701-15 Polyurethane Soft Seal Series

* Very soft with enhanced Stalability
* Thickness range from 0.510 to 12.7 mm (0.02 to 0.5 in.)
* Mainly apply to applied to waterproof sealing application

PORON EVExtend Material 4701-37&4701-41HBF

* EVExtend battery pad material
* Thickness range from 0.039 to 0.118 in (1 to 3 mm)
* Mainly apply to electric and Hybrid-Electric Vehicle batteries solution

PORON ThinStik Materials

* Combine PORON foams with a pressure sensitive adhesive
* Ultra-thin and highly compressible
* Long term protection and sealing




Rogers Bisco Silicone Series

BF-2000 Ultra Soft Silicone Foam

* Ultra Soft Silicone Foam with black color
* Thickness range from 3.18mm-12.7mm

BF-1000 Very Soft Silicone Foam

* Very Soft Silicone Foam
* Color available with white, black, grey
* Thickness range from 1.6mm-25.4mm

HT-870 Soft Silicone Foam

* Firmer and denser version of BF-1000
* Color available with black and red
* Thickness range from 1.6mm-12.7mm

HT-800 Medium Silicone Foam

* Firmer and denser version of BF-1000
* Color available with grey, black and red
* Thickness range from 0.79mm-12.7mm

HT-820 Medium Silicone Foam

* Firm grade cellular silicone foam with grey color
* Thickness range from 0.79mm-6.35mm

HT-840 Extra Firm Silicone Foam

* Very firm grade cellular silicone foam with grey color
* Thickness range from 1.6mm-6.35mm

HT-6000 Series Solid Silicones

* Available in soft to firm grades
* Available thickness: 0.78-3.175mm

HT-1200 Series Silicone Rubbers

* Available thickness 0.78-3.175mm

HT-200 Silicone Sound Barrier

* Available thickness: 0.635-3.81mm

HT-1500 Silicone Press Pad

* Available thickness:0.78-3.175mm
