MIKI Special Paper is a high quality specialty insulating paper (commonly known as kraft paper) made from selected wood pulp and processed using Miki's advanced paper making technology and equipment to meet the diverse insulating material needs of different customers.
MIKI special insulating paper has many specifications, and each specification has multiple thicknesses to meet the diversified needs of different customers for high quality.
Basic performance
MIKI special insulation paper, as a high-quality insulation paper produced from pure wood pulp, has the following characteristics:
• Excellent electrical insulation performance
• Numerous product specifications and thicknesses
• Excellent cost advantage
Product Information
Product specifications
MIKI Special Paper uses selected pure wood pulp as raw material and Miki's advanced papermaking technology and equipment to process high-quality special insulating paper (commonly known as kraft paper) to meet the diversified insulating material needs of different customers.
|
Specifications |
Thickness (mm) |
features |
|
CREPE |
0.35、0.46、0.65、0.80、1.15 |
MIKI wrinkled insulation paper, used for wrapping wires |
|
HD |
0.075 |
High density special insulation paper |
|
HPI-G |
0.05、0.075 |
Color: Green heat-resistant special high-density insulation paper |
|
IP-cb |
0.047、0.05、0.07、0.075 |
High density special insulation paper |
|
LD |
0.3、0.4、0.5、0.8、1.0 |
A type of fast bar insulation paper that has not been laminated and has low density, used in situations where density requirements are not high. |
|
PB2 |
0.10、0.13、0.18、0.25、0.38、0.50、0.80、1.0、1.2、1.6、2.00、2.50 |
Color: Wood color (yellow), red, green, gray black are used for motors, transformers, winding tubes, gaskets, capacitors, and composite materials |
|
PI2 |
0.03、0.04、0.05、0.06、0.075、0.08、0.09、0.10、0.13、0.18、0.25、0.38 |
Color: Wood color (yellow) is mainly used for speakers, cables, capacitors, composite materials |
|
Electronic component fixed paper tape |
0.08、0.10、0.13 |
Used for packaging electronic components |
|
BC-60 |
0.06 |
MIKI Immortal Flower Paper |
Other information
MIKI special insulation paper is mainly used in electrical products such as motors, generators, transformers, speakers, capacitors, winding tubes, gaskets. At the same time, it can be used as a composite substrate and combined with other insulation materials.
